Coating |
N/A (Multi-Layer TiN/TiCN/TiC/TiN) TiC |
Substrate |
N/A Tool Steel (A2, D2, DC53, S7, H13, etc.) High Speed Steel (HSS) (M2, M4, M42, T15, CPM 10V, Vanadis 4, etc.) 400 Stainless Steel (416, 420, 440C, etc.) Other Alloys (17-4, 13-8, 455, 465, etc.) Stellite Tungsten Carbide |
Coating Characteristics |
N/A Abrasion Resistant Wear Resistant Thin Film Hard Surface Chemical & Metallurgical Bond to Substrate High Micro-Hardness (2400 to 3400 HV) Low Coefficient of Friction (0.15 to 0.35) Anti-Galling |
PreCoating Preparation |
N/A Polishing |
PostCoating Preparation |
N/A Polishing Heat Treating |
Application Process |
N/A Chemical Vapor Deposition (CVD) |
Applications |
N/A Internal Surfaces Carbide Milling Tools Turning Inserts Wear Components Plastic Processing Tools Metal Forming Tools Punches Draw Dies Forging Tools Trim Dies Stamping Tools Wire Draw Dies Extrusion Dies Coining Dies Draw Plugs Swaging Dies Form Rolls Seaming Rolls Cold Heading Tools Crimping Tools Tube Bending Dies |
Average Film Thickness |
N/A 0.00024 to 0.00035 in0.006 to 0.009 mm |
Additional Services |
N/A Research & Development Quality Control Testing |
Part Size |
N/A Based on Customer Requirements |
Production Volume |
N/A Prototype Low Volume High Volume Blanket Orders |
Lead Times |
N/A Quoted on Job by Job Basis Emergency Services Available Rush Services Available |
Industry Focus |
N/A Aerospace Appliance Commercial Appliance Residential Architecture Auto/Truck/Transportation Automotive Biomedical Biotechnology Building & Construction Commercial Communications Consumer Goods Household Industrial Injection Molding Machine Tools Machinery Manufacturing Marine Medical Medical Devices Molding Oil & Gas Pipeline Power Generation Residential Tool & Die Transportation |
Industry Standards |
N/A ISO-9001:2015 - 3rd Party Certified ISO-13485:2016 - 3rd Party Certified (PA location only) ISO/TS 16949 - Compliance to Audit Criterion ISO 14001:2015 & OHSAS 18001:2007 - 2nd Party Certified 21 CFR Part 820 - Medical Device Quality System Regulation - 2nd Party Compliance CQI-12 - Special Process: Coating System Assessment NADCAP - AC 7109/2 - Compliance to Audit Criterion RoHS/REACH/WEEE Compliance Bureau of Alcohol, Tobacco, Firearms, and Explosives - Type 7 FFL and SOT Quality System Regulation 21 CFR Part 820 of the FDA ISO 10993 |
File Formats |
N/A PDF GIF JPEG DWG DXF PNG DOC/DOCX XLS/XLSX PPT/PPTX TIFF ZIP |
